GZP6866D:Gas Measurement Digital Pressure Sensor,Absolute Pressure Type
- Multiple range: 00kPa~700kPa...1100kPa
- Absolute pressure type
- Power supply voltage: 1.8V～3.6V
- Current consumption: <80uA (maximum oversampling rate for one measurement)
- Standby current: 0.1uA (at 25°C)
- High pressure accuracy
- Optional gel filling for waterproof application
- IIC Interface
- Temperature compensated
GZP6816D:Atmospheric Pressure Sensor, Absolute Pressure Type
- Multiple range: 30kPa~110kPa
- Absolute pressure type
- Power supply voltage: 1.8V～3.6V
- Current consumption: <80uA (maximum oversampling rate for one measurement)
- Standby current: 0.1uA (at 25°C)
- Absolute pressure accuracy: ±1hPa (8.3m)
- Relative pressure accuracy: ±0.12hPa (1m)
- IIC Interface
- Wide temperature compensation
GZP6830D:Low Comsumption Waterproof Pressure Sensor, I2C Digital Pressure Sensor
- Multiple range from 0 to 700...3000kPa
- Absolute pressure type
- Power supply voltage: 1.8V～3.6V
- Current consumption: <80uA (maximum oversampling rate for one measurement)
- Standby current: 0.1uA (at 25°C)
- Ceramic packaging structure, moisture-proof and oil-proof
- IIC Interface
- Temperature compensated
- High accuracy
GZP6181A:Coolant Pressure Transmitter for Cooling System from 1MPa to 5Mpa
- High accuracy pressure transducer
The accuracy over the entire service life at room temperature is better than ±1%FS.
The full-life accuracy of high and low temperature performance exceeds ±3%FS - Temperature range: -40℃ to 125℃
- Customizable for wide range up to 5Mpa
- Electrical strength: AC 1500V (1 minute) / 1800V (1 second), leakage current ≤0.75mA
- Exceptional overvoltage protection against reverse polarity, supporting 18V overvoltage and-14V reverse polarity
- Proportional/Fixed analog voltage output (customizable)
- Output Clamping (Customizable)
GZP6183A-AS: Air Brake Pressure Sensor for Commercial Vehicle
- High accuracy pressure transducer
The accuracy over the entire service life at room temperature is better than ±1%FS
The full-life accuracy of high and low temperature performance exceeds ±3%FS - Temperature range: -40℃ to 125℃
- Customizable for wide range up to 5Mpa
- Insulation parameter: >10 MΩ/500 V DC
- Exceptional overvoltage protection, supporting 36V overvoltage and-28V reverse polarity
- Proportional/Fixed analog voltage output (customizable)
- Output Clamping (Customizable)
GZP6183A-AU:Engine Oil Pressure Sensor, 3x Pressure Range Burst
- High accuracy pressure transducer
The accuracy over the entire service life at room temperature is better than ±1%FS
The full-life accuracy of high and low temperature performance exceeds ±3%FS - Temperature range: -40℃ to 125℃
- Customizable for wide range up to 5Mpa
- Insulation parameter: >10 MΩ/500 V DC
- Exceptional overvoltage protection, supporting 36V overvoltage and-28V reverse polarity
- Proportional/Fixed analog voltage output (customizable)
- Output Clamping (Customizable)
GZP6185A-J:Moter Oil Pressure Sensor
- High accuracy pressure transducer
The accuracy over the entire service life at room temperature is better than ±1%FS
The full-life accuracy of high and low temperature performance exceeds ±3%FS - Temperature range: -40℃ to 125℃
- Customizable for wide range up to 5Mpa
- Insulation parameter: >10 MΩ/500 V DC
- Exceptional overvoltage protection, supporting 18V overvoltage and-14V reverse polarity
- Proportional/Fixed analog voltage output (customizable)
- Output Clamping (Customizable)
GZP6185A:Air Pump Pressure Transducer with 4-20mA Output 1mPa/1.6mPa/2.5mPa
- High accuracy pressure transducer
The accuracy over the entire service life at room temperature is better than ±1%FS
The full-life accuracy of high and low temperature performance exceeds ±3%FS - Temperature range: -40℃ to 125℃
- Customizable for wide range up to 5Mpa
- Electrical strength: AC 1500V (1 minute) / 1800V (1 second), leakage current ≤0.75mA
- Excellent overvoltage and reverse polarity protection
- Proportional/Fixed analog voltage output (customizable
- Output Clamping (customizable)
GZR6191A:Crankshaft Sensor，High-temperature Resistant foe Car Braking System
- High-performance speed sensor
- High temperature resistance
- One-piece injection molding, dimensional stability
The product utilizes a high-flux, stable samarium-cobalt magnet as its magnetic field source, and employs low-coercivity, high-permeability electromagnetic pure iron to improve the utilization rate and response time of the permanent magnet's magnetic field. High-temperature resistant, high-pulse-voltage enameled wire is used as the signal generation source. Finally, the coil, permanent magnet, and electromagnetic pure iron are assembled and injection molded. The product process is simple, the injection molding consistency is good, the size is small, and the cost is low.
GZR6192D:Camshaft Sensor, All-in-one Injection Moulded High-precision Sensor
- High-precision speed sensor
- High stability
- Integrated injection molding structural solution
Utilizing imported Hall effect chips from renowned brands ensures high output accuracy and reliability. Using samarium cobalt magnets provides a constant back magnet, guaranteeing both performance and high stability. The integrated injection molding design reduces the number of parts and shortens the manufacturing process, lowering material and production costs.
GZP6812D:Low Comsumption Pressure Sensor for Tire Pressure Meter, 1.8V～3.3V
- Multiple range: 00kPa~700kPa...5500kPa
- Absolute pressure type
- Power supply voltage: 1.8V～3.6V
- Current consumption: <80uA (maximum oversampling rate for one measurement)
- Standby current: 0.1uA (at 25°C)
- High pressure accuracy
- Optional gel filling for waterproof application
- IIC Interface
- Temperature compensated
