GZR6191A:Crankshaft Sensor，High-temperature Resistant foe Car Braking System
- High-performance speed sensor
- High temperature resistance
- One-piece injection molding, dimensional stability
The product utilizes a high-flux, stable samarium-cobalt magnet as its magnetic field source, and employs low-coercivity, high-permeability electromagnetic pure iron to improve the utilization rate and response time of the permanent magnet’s magnetic field. High-temperature resistant, high-pulse-voltage enameled wire is used as the signal generation source. Finally, the coil, permanent magnet, and electromagnetic pure iron are assembled and injection molded. The product process is simple, the injection molding consistency is good, the size is small, and the cost is low.
Description
GZR6891A: Rotation Speed Sensor
| Sensor Attribute | Attribute Value |
| Product Category | Rotation Speed Sensor |
| Product Series | GZR6191A |
| Sensor Type | Magneto-electric |
| Rotation Range | 0～3000R/Min |
| Power Supply Type | None |
| Resistance | 860 ±86 Ω |
| Inductance | 370 ± 60mH |
| Insulation Resistance | ≥10MΩ/500VDC |
| Operating Temperature | -40 to 150°C |
| Manufacture Technics | Injection Molding |
| Electrical Port | AMP 936059 or BOSCH 1 928 403 874 |
| Protection level | IP67 |
| Cycle Life | ＞ 1 Million |
| Application | OEM-fitted Automotive application |
Product Description
The GZR6191A is a mature and reliable passive magnetoelectric rotation speed sensor product launched by Sencoch for the automotive market. The product has no circuit module; its structure mainly consists of a coil, permanent magnet, magnetically conductive pure iron, terminals, flange gaskets, and sealing rings, all injection molded into a single unit. The product has a simple structure and good performance consistency.
APPLICATIONS & DIMENSION
Applications
This product is primarily targeted at the commercial vehicle and passenger vehicle markets, where it is applied to the engine powertrain to measure the rotational speed and position of the engine camshaft and crankshaft, as well as to detect the wheel speed for ABS in the braking system.
Dimension
More information about GZP6191A, refer to Datasheet or contact Sencoch
